End Mill Manufacturers

Scientific name	Composition	Physical properties	Features	Typical applications
TiN General	Titanium nitride coating (PVD), classic “gold” coating for improved wear resistance and lubricity.	Colour: gold. Hardness: ~2000–2300 HV. Friction: ~0.4–0.6. Temp. resistance: ~500–600°C.	Improves tool life vs uncoated; good all-round coating for moderate speed, moderate heat cutting.	Mild steel, alloy steel, cast iron. Suitable for general milling, drilling, tapping (low-to-mid speed).
TiCN Wear	Titanium carbonitride (PVD). Higher hardness than TiN; better abrasion resistance.	Colour: blue-grey / violet-grey. Hardness: ~2800–3200 HV. Friction: ~0.3–0.5. Temp. resistance: ~400–500°C.	Strong wear resistance and edge protection; good for interrupted cuts and higher abrasion materials.	Carbon steel, alloy steel, cast iron, abrasive materials. Good for milling with stable rigidity.
TiAlN Hot cutting	Titanium aluminium nitride (PVD). Al improves oxidation resistance and forms protective Al₂O₃ layer.	Colour: violet / purple. Hardness: ~3200–3500 HV. Oxidation resistance: ~800–900°C. Best mode: dry / high-speed.	Excellent heat resistance and wear resistance; suitable for high-speed dry milling and hard-to-cut steels.	Alloy steel, hardened steel, cast iron. Great for high-speed milling, slotting, and roughing.
AlTiN High heat	Aluminium titanium nitride (PVD) with higher Al content than TiAlN, improving oxidation resistance further.	Colour: dark violet / blackish purple. Hardness: ~3300–3800 HV. Oxidation resistance: up to ~900°C+. Thermal stability: excellent.	Handles very high temperature and heavy loads; ideal for aggressive machining and longer tool life.	Hardened steel (HRC), alloy steel, cast iron. Recommended for high-speed roughing and deep milling.
AlCrN Stainless	Aluminium chromium nitride (PVD). Combines oxidation resistance with better toughness and smoother cutting.	Colour: dark grey. Hardness: ~3000–3500 HV. Oxidation resistance: ~900–1100°C (process dependent). Adhesion: strong to substrate.	Great for stainless steels and nickel alloys; resists chipping and maintains stability under heat.	Stainless steel (304/316), tool steel, Inconel/Ni alloys, titanium alloy. High-performance milling.
CrN Non-ferrous	Chromium nitride (PVD). Smoother surface and good toughness; more anti-adhesion than TiAlN for some materials.	Colour: silver-grey. Hardness: ~1800–2200 HV. Friction: ~0.3 (typical). Temp. resistance: ~700°C.	Balanced option for mixed cutting; good finish and stable performance, less prone to built-up edge than TiAlN.	Aluminium alloys, copper alloys, mild steel, plastics. General purpose milling and finishing.
ZrN Al finish	Zirconium nitride (PVD). Smooth and chemically stable; often chosen for non-ferrous finishing.	Colour: light gold / champagne. Hardness: ~2200–2500 HV. Friction: relatively low. Temp. resistance: ~600–700°C.	Excellent finish on aluminium; reduces sticking and improves surface brightness; good for finishing passes.	Aluminium, brass, copper. Ideal for finishing end mills where surface quality is critical.
DLC Anti-stick	Diamond-like carbon (a-C:H) coating (PVD), extremely smooth with ultra-low friction.	Colour: black / dark grey. Hardness: ~2000–3000 HV. Friction: very low (~0.05–0.15). Temp. resistance: ~350–400°C.	Best anti-adhesion for aluminium; improves chip flow and surface finish; extends tool life on non-ferrous materials.	Aluminium alloys (6061/7075), copper, plastics, composites. Strongly recommended for high-speed Al milling.

Scientific
name

Composition

Physical properties

Features

Typical applications

TiN
General

Titanium nitride coating (PVD), classic “gold” coating for improved wear resistance and lubricity.

Colour: gold.
Hardness: ~2000–2300 HV.
Friction: ~0.4–0.6.
Temp. resistance: ~500–600°C.

Improves tool life vs uncoated; good all-round coating for moderate speed, moderate heat cutting.

Mild steel, alloy steel, cast iron. Suitable for general milling, drilling, tapping (low-to-mid speed).

TiCN
Wear

Titanium carbonitride (PVD). Higher hardness than TiN; better abrasion resistance.

Colour: blue-grey / violet-grey.
Hardness: ~2800–3200 HV.
Friction: ~0.3–0.5.
Temp. resistance: ~400–500°C.

Strong wear resistance and edge protection; good for interrupted cuts and higher abrasion materials.

Carbon steel, alloy steel, cast iron, abrasive materials. Good for milling with stable rigidity.

TiAlN
Hot cutting

Titanium aluminium nitride (PVD). Al improves oxidation resistance and forms protective Al₂O₃ layer.

Colour: violet / purple.
Hardness: ~3200–3500 HV.
Oxidation resistance: ~800–900°C.
Best mode: dry / high-speed.

Excellent heat resistance and wear resistance; suitable for high-speed dry milling and hard-to-cut steels.

Alloy steel, hardened steel, cast iron. Great for high-speed milling, slotting, and roughing.

AlTiN
High heat

Aluminium titanium nitride (PVD) with higher Al content than TiAlN, improving oxidation resistance further.

Colour: dark violet / blackish purple.
Hardness: ~3300–3800 HV.
Oxidation resistance: up to ~900°C+.
Thermal stability: excellent.

Handles very high temperature and heavy loads; ideal for aggressive machining and longer tool life.

Hardened steel (HRC), alloy steel, cast iron. Recommended for high-speed roughing and deep milling.

AlCrN
Stainless

Aluminium chromium nitride (PVD). Combines oxidation resistance with better toughness and smoother cutting.

Colour: dark grey.
Hardness: ~3000–3500 HV.
Oxidation resistance: ~900–1100°C (process dependent).
Adhesion: strong to substrate.

Great for stainless steels and nickel alloys; resists chipping and maintains stability under heat.

Stainless steel (304/316), tool steel, Inconel/Ni alloys, titanium alloy. High-performance milling.

CrN
Non-ferrous

Chromium nitride (PVD). Smoother surface and good toughness; more anti-adhesion than TiAlN for some materials.

Colour: silver-grey.
Hardness: ~1800–2200 HV.
Friction: ~0.3 (typical).
Temp. resistance: ~700°C.

Balanced option for mixed cutting; good finish and stable performance, less prone to built-up edge than TiAlN.

Aluminium alloys, copper alloys, mild steel, plastics. General purpose milling and finishing.

ZrN
Al finish

Zirconium nitride (PVD). Smooth and chemically stable; often chosen for non-ferrous finishing.

Colour: light gold / champagne.
Hardness: ~2200–2500 HV.
Friction: relatively low.
Temp. resistance: ~600–700°C.

Excellent finish on aluminium; reduces sticking and improves surface brightness; good for finishing passes.

Aluminium, brass, copper. Ideal for finishing end mills where surface quality is critical.

DLC
Anti-stick

Diamond-like carbon (a-C:H) coating (PVD), extremely smooth with ultra-low friction.

Colour: black / dark grey.
Hardness: ~2000–3000 HV.
Friction: very low (~0.05–0.15).
Temp. resistance: ~350–400°C.

Best anti-adhesion for aluminium; improves chip flow and surface finish; extends tool life on non-ferrous materials.

Aluminium alloys (6061/7075), copper, plastics, composites. Strongly recommended for high-speed Al milling.

Each HNCarbide end mill is designed for high-speed machining of aluminum, plastics, copper, and soft alloys, delivering efficient chip evacuation and stable cutting performance. As professional end mill manufacturers, we produce precision-ground tools with optimized flute geometry to reduce cutting resistance and ensure clean surface finish.

Recognized among reliable carbide end mill manufacturers and trusted by buyers sourcing from carbide end mill manufacturers USA and end mill manufacturers USA, HNCarbide provides consistent quality and machining stability. As experienced solid carbide end mill manufacturers and competitive china cnc rough end mill manufacturers, we support both precision finishing and heavy-duty applications.

For customers evaluating global end mill cutter manufacturers or comparing the best end mill manufacturers, our tools offer stable performance at high RPMs and feed rates, making them ideal for CNC routers and machining centers.

✔ Fast chip evacuation
✔ Clean edge finish
✔ Stable cutting performance
✔ Long tool life

At HNCarbide, as one of the professional end mill manufacturers and competitive carbide end mill manufacturers, every spiral end mill and up spiral router bit with bearing is carefully packaged to protect your tools from factory to job site. Each tool is individually encased in a shock-resistant sleeve and clearly labeled with full specifications, including tool type (up spiral router bit or down spiral option), size range (1/8, 1/4, 3/8, 1/2 inch and 3mm–20mm), and common shank options such as 1/4 shank. This packaging standard applies equally to up spiral router bit with top bearing and up spiral router bit with bottom bearing configurations.

Recognized among reliable solid carbide end mill manufacturers and trusted by buyers sourcing from carbide end mill manufacturers USA and established end mill manufacturers USA suppliers, we ensure every label clearly identifies special variants such as left hand spiral end mill, left hand spiral right hand cut end mill, or left hand spiral left hand cut end mill when required. Bearing configurations—including up spiral router bit with bearing, top bearing, or bottom bearing designs—are clearly marked for quick and accurate tool selection in CNC routing and machining centers.

As experienced china cnc rough end mill manufacturers and dependable end mill cutter manufacturers, we reinforce bulk orders with double-wall corrugated cartons or export-grade wooden crates. Through trusted logistics partners, our tools are shipped securely by air, sea, or express courier—ensuring safe delivery and readiness for high-performance machining.
